Key Takeaways & Executive Findings
- •• Micro CT imaging revealed that the scaphoid waist has sparser trabecular bone and lower bone density, making it the most fracture-prone region. • Significant regional differences in trabecular microstructure parameters were found among the tubercle, waist, and body of the scaphoid. • Left-right differences were significant only in the tubercle, not in the waist or body. • The findings provide a microstructural basis for understanding scaphoid fracture mechanisms and designing internal fixation devices.
Abstract
BACKGROUND: Clinically, due to the special anatomical characteristics and internal trabecular bone distribution of the scaphoid, the treatment effect of fractures is generally poor, often leading to nonunion and ischemic necrosis, which in turn causes wrist arthritis and loss of function. OBJECTIVE: To scan scaphoid specimens using Micro CT technology, analyze their internal microstructure characteristics, measure the trabecular bone microstructure parameters in each region, and discover regional differences in scaphoid trabecular bone, aiming to provide a scientific basis for the prevention, treatment, and fracture mechanism research of scaphoid fractures. METHODS: Bilateral scaphoid bones (10 cases) from 5 adult cadaver specimens were scanned by Micro CT. By selecting and reconstructing trabecular bone in three regions of interest (tubercle, waist, and body), the internal micromorphological characteristics of the scaphoid were observed in detail, and the differences in trabecular bone microstructure parameters among regions were measured and compared. RESULTS AND CONCLUSION: (1) Micro CT images showed that the cortical bone on the surface of the scaphoid was relatively thin, and the interior was filled with complex trabecular bone microstructure; the lamellar trabecular bone near the cortical bone was relatively dense, extending inward into rod-like trabecular bone. From sagittal, coronal, and transverse sections, the trabecular bone distribution in the waist was relatively sparse, while that in the body and tubercle was denser. (2) There were significant differences in bone volume fraction, bone surface area, bone surface area to tissue volume ratio, trabecular separation, trabecular number, trabecular connectivity, trabecular connection density, fractal dimension, bone mineral density, and bone mineral content of the scaphoid tubercle between left and right sides (P < 0.05). There were no significant differences in the trabecular bone microstructure parameters of the waist and body between left and right sides (P > 0.05). (3) There were significant differences in bone volume, bone volume fraction, bone surface area, bone surface area to tissue volume ratio, bone surface area to bone volume ratio, bone mineral density, and bone mineral content between the body and the tubercle/waist (P < 0.05). There was a significant difference in trabecular thickness between the body and the tubercle (P < 0.05). There were significant differences in trabecular separation and fractal dimension among the body, tubercle, and waist (P < 0.05). There were significant differences in trabecular number, trabecular connectivity, and trabecular connection density between the waist and the tubercle/body (P < 0.05). There were no significant differences in tissue volume and degree of anisotropy among the body, tubercle, and waist (P > 0.05). (4) The results showed that the trabecular bone microstructure parameters of the scaphoid had regional differences, among which the waist had lower bone density and strength, making it the most prone to fracture. This finding provides a theoretical basis for understanding the fracture mechanism of the scaphoid from the perspective of trabecular bone microstructure. At the same time, the trabecular bone structure characteristics of different parts of the scaphoid revealed in this study also provide a theoretical basis for designing targeted internal fixation instruments.
1. Introduction
The scaphoid is one of the important bones constituting the wrist joint. Its shape is long and arched, similar to a boat, and it is very irregular [1]. Due to the lack of obvious boundaries, the scaphoid can be divided into three parts according to its function: the tubercle, waist, and body [2]. The incidence of scaphoid fractures is second only to distal radius fractures in the wrist, accounting for about 70% of all carpal bone injuries [3]. Among all scaphoid fractures, waist fractures are the most common [4-5]. Because of the unique anatomical structure of the scaphoid, such as a slender waist and insufficient blood supply, fractures are prone to complications such as ischemic necrosis and delayed union.
In this study, Micro CT technology was used to scan scaphoid specimens, analyze the internal microstructure characteristics, and measure the trabecular bone microstructure parameters in different regions. The aim was to discover regional differences in scaphoid trabecular bone and provide a scientific basis for the prevention, treatment, and fracture mechanism research of scaphoid fractures.
Loading authentic research manuscript (Pages 1–5)...
ZHANG Dezhou, LYU Yuan, LI Kun, CHEN Jie, YANG Xiangrong, ZHAO Hailong, ZHANG Shaojie, MA Yuan, HAO Yunteng, YANG Yang, GAO Mingjie, WANG Zhiqiang, LI Zhijun, SHI Jun, WANG Xing (2026). Micromorphological characteristics of human scaphoid bone based on Micro CT imaging technology. Chinese Journal of Tissue Engineering Research. https://doi.org/10.12307/2026.21418
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoBioData are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoBioData claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the significance of Micro CT in studying scaphoid fractures?
Micro CT provides high-resolution three-dimensional imaging that allows non-destructive visualization of the internal microstructure of small samples. In this study, it enabled detailed analysis of trabecular bone architecture in different regions of the scaphoid, revealing regional differences that help explain fracture susceptibility and guide treatment.
Which region of the scaphoid is most prone to fracture and why?
The waist of the scaphoid is most prone to fracture. The study found that the waist has sparser trabecular bone and lower bone density compared to the tubercle and body, making it structurally weaker and more susceptible to fracture.
What were the key findings regarding left-right differences in scaphoid trabecular bone?
Significant left-right differences were observed only in the tubercle region for several parameters, including bone volume fraction and bone mineral density. No significant left-right differences were found in the waist and body regions.
How can these findings influence clinical treatment of scaphoid fractures?
Understanding the regional variations in trabecular bone microstructure can help in designing targeted internal fixation devices and improving surgical approaches. It also provides a theoretical basis for predicting fracture risk and developing preventive strategies.
