Key Takeaways & Executive Findings
- •• Laser power and scanning speed are the most influential parameters affecting clad geometry and dilution. • The optimized parameters (1.8 kW, 6 mm/s, 12 g/min) yield a dilution of 8.5% and microhardness of 650 HV. • Response surface methodology effectively models and optimizes laser cladding process parameters. • The Ni-based coating exhibits uniform microstructure and strong metallurgical bonding, enhancing surface properties.
Abstract
Laser cladding is an advanced surface modification technique used to enhance the wear and corrosion resistance of metallic components. In this study, Ni-based coatings were deposited on 316L stainless steel substrates using a fiber laser. The influence of laser power, scanning speed, and powder feed rate on the geometrical characteristics (clad height, width, and dilution) and microhardness of the clad layer was investigated. Response surface methodology (RSM) based on a central composite design was employed to develop empirical models and optimize the process parameters. The results indicated that laser power and scanning speed significantly affect the clad geometry, while powder feed rate has a moderate effect. The optimized parameters were found to be laser power of 1.8 kW, scanning speed of 6 mm/s, and powder feed rate of 12 g/min, resulting in a dilution of 8.5% and a microhardness of 650 HV. The clad layer exhibited a uniform microstructure with good metallurgical bonding to the substrate. This study provides a systematic approach for parameter optimization in laser cladding, which is beneficial for industrial applications requiring high-performance coatings.
1. Introduction
Laser cladding is a versatile surface engineering technique that involves the deposition of a coating material onto a substrate using a high-energy laser beam. It offers numerous advantages over conventional methods, including minimal heat input, low dilution, and the ability to produce metallurgically bonded coatings with superior properties. In industries such as automotive, aerospace, and tooling, laser cladding is employed to improve wear resistance, corrosion resistance, and overall service life of components.
316L stainless steel is widely used due to its excellent corrosion resistance, but its relatively low hardness limits its application in abrasive environments. Ni-based coatings are often applied to enhance surface hardness and wear resistance while maintaining corrosion resistance. However, the quality of the clad layer is highly dependent on process parameters such as laser power, scanning speed, and powder feed rate. Improper selection can lead to defects like porosity, cracking, and excessive dilution, which degrade performance.
Therefore, optimization of these parameters is crucial to achieve desired clad characteristics. Response surface methodology (RSM) is a statistical tool that enables the modeling and optimization of processes with multiple variables. This study aims to systematically investigate the effects of process parameters on clad geometry and microhardness, and to determine the optimal settings for Ni-based laser cladding on 316L steel.
Loading authentic research manuscript (Pages 1–5)...
A. Kumar, S. Singh, R. Kumar (2026). Optimization of Process Parameters for Laser Cladding of Ni-Based Coating on 316L Steel Using Response Surface Methodology. Chinese Traditional and Herbal Drugs. https://doi.org/10.1007/s12666-024-03345-6
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoBioData are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoBioData claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What is the optimal laser power for Ni-based laser cladding on 316L steel?
The optimal laser power was found to be 1.8 kW, which resulted in a dilution of 8.5% and a microhardness of 650 HV.
How does scanning speed affect the clad geometry?
Scanning speed significantly influences clad height and width; higher speeds generally reduce the amount of material deposited per unit length, leading to thinner and narrower clads.
What are the key advantages of using response surface methodology in laser cladding?
RSM allows for efficient modeling of the relationship between process parameters and responses, reducing the number of experiments required and enabling the identification of optimal parameter settings.
What is the significance of dilution in laser cladding?
Dilution refers to the mixing of substrate material into the coating. Low dilution is desirable to maintain the coating's properties, but too low may indicate poor bonding. The optimal dilution in this study was 8.5%.
Can the optimized parameters be applied to other substrate materials?
While the optimized parameters are specific to 316L steel and Ni-based powder, the methodology can be adapted to other material combinations by conducting similar experiments.
