Key Takeaways & Executive Findings
- •• Optimizing layer height, extrusion temperature, and printing speed improves tensile strength by up to 32% and flexural strength by 28% in 3D-printed CFRP composites. • Reduced void content and enhanced fiber-matrix adhesion are key microstructural factors contributing to improved mechanical properties. • The study establishes a process-property relationship that enables tailored manufacturing of CFRP parts for structural applications. • The optimal parameter set offers a practical benchmark for industrial adoption of FFF-based CFRP production.
Abstract
This study investigates the influence of key process parameters on the mechanical properties of continuous carbon fiber reinforced polymer (CFRP) composites fabricated via fused filament fabrication (FFF). A systematic experimental design was employed to evaluate the effects of layer height, extrusion temperature, and printing speed on tensile strength, flexural strength, and interlaminar shear strength. The results indicate that optimizing these parameters can significantly enhance the mechanical performance, with an optimal combination yielding a 32% increase in tensile strength and a 28% improvement in flexural strength compared to baseline. Microstructural analysis revealed improved fiber-matrix adhesion and reduced void content in optimized samples. The findings provide practical guidelines for the additive manufacturing of high-performance CFRP components.
1. Introduction
Additive manufacturing (AM) has revolutionized the production of complex geometries, and continuous carbon fiber reinforced polymer (CFRP) composites have gained attention for their high strength-to-weight ratio. Fused filament fabrication (FFF) is a widely used AM technique, but the mechanical properties of printed CFRP parts are often inferior to those of conventionally manufactured composites due to process-induced defects. This study aims to systematically investigate the influence of critical process parameters on the mechanical performance of FFF-printed CFRP composites.
Previous research has explored the effects of individual parameters, but a comprehensive understanding of their interactions is lacking. This work employs a design of experiments approach to optimize layer height, extrusion temperature, and printing speed, and evaluates the resulting tensile, flexural, and interlaminar shear properties. The findings are expected to provide valuable insights for process optimization and quality control in additive manufacturing of CFRP components.
Loading authentic research manuscript (Pages 1–5)...
J. Zhang, L. Wang, M. Chen, R. Liu (2026). Enhancing the Mechanical Properties of 3D-Printed Continuous Carbon Fiber Reinforced Polymer Composites via Process Parameter Optimization. Chinese Journal of New Drugs. https://doi.org/10.1007/s12289-025-01845-7
Research & Educational Purpose Only:The translations, structured abstracts, analytical annotations, and data reports provided by SinoBioData are intended exclusively for academic research, internal corporate R&D, and educational benchmarking. They do not constitute formal engineering, chemical safety, legal, or professional advice.
Copyright & Intellectual Property Notice: Original copyright of the underlying source articles and experimental data remains with the respective authors, institutions, and original publishing journals. SinoBioData claims intellectual property only over its proprietary translations, analytical syntheses, and AEO structured enhancements in accordance with international fair use and academic citation principles.
Frequently Asked Questions
What are the optimal process parameters for 3D-printed CFRP composites?
The optimal parameters identified in this study are a layer height of 0.15 mm, extrusion temperature of 260°C, and printing speed of 30 mm/s, which resulted in the highest mechanical properties.
How does layer height affect the mechanical properties of 3D-printed CFRP?
Smaller layer heights generally improve interlaminar bonding and reduce void content, leading to higher tensile and flexural strengths, but excessively small heights can cause processing issues.
What is the significance of extrusion temperature in FFF of CFRP?
Extrusion temperature influences the viscosity of the polymer matrix and the wetting of carbon fibers. An optimal temperature ensures good fiber-matrix adhesion without thermal degradation.
Can the findings be applied to other fiber types?
While the study focuses on carbon fibers, the methodology and trends may be transferable to other continuous fiber composites, though specific optimal parameters may vary.
What are the main defects in 3D-printed CFRP composites?
Common defects include voids, poor fiber-matrix adhesion, and fiber misalignment, which can be mitigated through process parameter optimization.
